Cross Stitch Pattern Grid

Create custom cross stitch grids with color palettes and stitch count calculations.

Tested tool guide Tested browser tools Checked August 16, 2026

What Cross Stitch Pattern Grid does, with a checked example

A cross stitch pattern is a grid: each cell is one stitch, and each palette color is one thread color. The tool gives you an empty grid sized in stitches and a palette of thread colors; you assign a color to each cell, and it tallies stitches per color and in total as you work, so you know exactly how many stitches each color needs before you buy thread. The thing people trip on first is the unit: the grid is measured in stitches, not inches. On 14-count Aida there are 14 stitches per inch, so a 40-stitch-wide design is only about 2.9 inches across.

Worked example

A concrete input and expected output from the current implementation.

Input

Grid: 40 stitches wide, 30 stitches high. Palette: 8 thread colors.

Expected output

A 40 x 30 grid of 1200 cells, one cell per stitch, with 8 palette colors. Total stitch count: 1200. Per-color stitch counts update as cells are colored and always add up to 1200.

A cross stitch grid has exactly one cell per stitch, so the total is width times height: 40 x 30 = 1200. Because every cell is exactly one color, the per-color counts must sum to that total, so the tool's counts and the grid always reconcile.

How the result is produced

1

Grid and palette

You set the grid's width and height in stitches, and the tool draws one cell per stitch. A palette holds the thread colors you plan to use; each cell is assigned exactly one palette color, so the design stays limited to threads you actually chose. Per-cell color assignment is also what makes per-color stitch counting possible.

2

Counting and reconciliation

Every colored cell adds one stitch to that color's tally and one to the running total, so the counts always reconcile: total stitches equals width times height, and the per-color counts sum to that total exactly. The tallies are derived from the grid rather than entered by hand, so a change to the grid updates every affected count at once.

Good uses

  • Fitting a motif to a hoop or frame. A 6-inch hoop on 14-count Aida holds about 84 stitches across (6 x 14 = 84), so you size the grid to that width and keep an eye on the stitch total as the design grows.
  • Buying floss before you start. The per-color stitch counts tell you how much of each color a design actually needs, so you can order skeins instead of guessing, running out mid-project, or overbuying colors that end up being only a few stitches.
  • Recreating a pixel image or existing chart as a stitchable pattern. Set the palette to the colors you want, then copy the image cell by cell onto the grid; keeping rows and columns aligned is far easier on a gridded canvas than on plain paper.

Limits and checks

  • The width and height boxes are stitches, not inches. A 12 means 12 stitches, which is under an inch on 14-count Aida (12 divided by 14 is about 0.9 inches). Convert inches to stitches by multiplying by the fabric count before you enter anything, or the finished piece comes out much smaller than planned.
  • Totals are exact; thread estimates are not. The count assumes every stitch is a full cross stitch. Half and quarter stitches, backstitch outlines, and the number of floss strands you use are not reflected in the grid or its counts, so detailing-heavy designs can run short despite the tally.
  • Changing the fabric count changes the finished size, not the stitch count. A 1200-stitch design is 1200 stitches on 14-count or 18-count fabric; only the inches change, and the piece gets smaller on the finer fabric. Expecting the tally to drop when you switch fabric is a common misread of the results.

Common questions

How do I convert a size in inches into grid stitches?

Multiply the inches by the fabric count. A 4-inch-tall motif on 14-count Aida is 4 x 14 = 56 stitches tall, so set the grid height to 56. Going the other way, divide stitches by the fabric count to get the finished size in inches. The grid is always in stitches; the fabric count is the conversion factor between the two.

Can the tool tell me how much thread to buy?

It tells you stitches per color exactly, one cell per stitch, and that number is reliable. Skein counts are a separate estimate you have to make: floss use depends on strands per stitch, fabric count, and personal tension, none of which the grid models. Budget extra thread for your heaviest colors and any backstitch work.

References and verification

The example and behavioral notes were checked against the browser implementation. Standards and primary references below define the relevant format, formula, or platform behavior.
